Dual Functionality

This system can switch between front-of-house mixing and/or stage monitor mixing, offering up to 6 monitor sends using 100mm faders.

Frames

Includes 24 frames, featuring 2 stereo channels with 100mm faders and inserts.

Stereo Channels

There are 2 stereo channels, each equipped with a 4-band EQ, full routing, and mute options. The inputs include mono mic and stereo line.

Stereo Returns

The system has 2 stereo returns, each with 60mm faders, EQ, and auxiliary sends.

Audio Groups

There are 4 audio groups with panned subgrouping to LR (Left and Right).

Auxiliary Sends

Six auxiliary sends are available, with 1-4 and 5-6 switchable between pre/post. You can reverse these sends with fader masters for monitor mode.

4-Band EQ

Separate controls for the mid-band sweeps allow for precise frequency enhancement at key points.

Filter

Includes a switchable high-pass filter (HPF) at 100Hz.

Phantom Power

Switchable phantom power is available on each channel.

Channel Meters

Each channel features 4-LED meters next to the faders, providing instant signal readings.

Talkback

Talkback can be sent to the groups, LR, and pairs of auxiliaries.

Direct Outputs

Every mono channel has a direct TRS output for recording and dedicated effects.

Engineer's Toolbox

Features comprehensive AFL/PFL monitoring, input/output and master metering, a headphone socket, and an oscillator/pink noise generator for setup.

Lamp Socket

A BNC connector is located in the master section for a lamp.

Expansion

The Sys-Link V1 option allows connection to other consoles fitted with Sys-Link 1.

PSU

Built-in power supply with a combiner socket.

Configuration Options

You can configure individual auxiliary sends as pre/post fader and pre-EQ. The direct output can be set to pre-fade, and pre-fade auxiliaries can be isolated from the channel mute. There are internal solder link options to configure pre-fade auxiliaries and direct outputs, with an option for electronic balance on the auxiliaries.

Features

Four group and six aux busses, Allen and Heath’s excellent 4-band EQ with swept mids, input
metering, channel direct outs, comprehensive engineer’s setup tools and talkback combine to
make GL2200 a truly versatile mixer for live performances.

24 mic/line inputs on XLR sockets
Dual front-of-house/monitor mode
4 group master busses
6 switchable auxilliary outputs
Direct out on every channel
Dimensions 920x155x572mm
Weight 24kg

More Information

More Information
Additional Information	FOH/stage-monitor dual functionality 4 groups, 6 auxes Groups, auxes and L, R and M outs 2 stereo line channels with mic capability 2 stereo returns with faders, EQ and aux sends Channel direct outs 2-track send and return 4-band EQ with swept mids and in/out switch Input metering on each channel Phantom 48V, switchable on each channel Inserts on all mono inputs Inserts groups (auxes) and L-R outs Comprehensive AFL/PFL monitoring Pink noise generator for speaker setup Oscillator for equipment line up Talkback facility High-performance internal power supply Built-in combiner for external power supply Console lamp connector Sys-linkTM expandability Rugged build quality 920mm Wide 572mm Deep 155mm High 24kg Weight
